Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505

Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505

An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.

Specification:- Fast Road
Pump:-  476459E
Voltage:- 12v
Earth:- Neg
Pressure (Psi):- 6.0-7.0
Flow:- US Gallons/Hr 35
Dry Prime Height in Mtrs:- 0.6
Thread Size:- 1/8th nptf
Operating Temperature:- -40º to +180° F (all Models)

Average Run Time or MTBF:- 6000 hrs

Legal Requirements:- Certified & Complies With EEC 95/54 Requirements

Length:-140mm

Diameter:- 54mm

Weight:-0.7kg

Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight

Applications:- Motorsport, Marine

Cross Reference:-
